H2050R Tabletop High Speed and Large-capacity Refrigerated Centrifuge

11 types of rotors are available for diversified centrifugal applications, supporting 4x 750ml large-capacity rotor as well as the rotor with max. speed up to 20500 rpm.

Features

◆11 types of rotors are available, offering large capacity and high speed centrifugal applications.

◆Microprocessor control, direct drive by AC inverter and brushless motor with high torque for long service life.

◆Touch panel, large LCD , and under programmable operation.

◆9 Acc profiles and 10 Dec profiles(0 is for free stop), 3-stage vibration damping, achieving ideal centrifugal result.

◆Triple-protective functions against imbalance, over-temperature and over-speed running for safe operation.

◆Automatic rotor recognition,and speed-limit control to ensure safety.

◆The operation temperature can be kept at -4℃ even when the rotors running at the max. speed due to the high efficient compressor with environment-friendly refrigeration system.

Technical Parameters

Rotor Optional

No.5 Swing Rotor Order No: 0302851300 Max.Speed: 5000rpm RCF: 3500xg Capacity: 4x750ml	Test Cup Order No: 0303891025 Capacity: 4x750ml Air tightness cup Order No 0303891006 Capacity: 4x750ml	Adapter	Capacity	Place	Diameter	Depth	Order No
			500ml (conical)	4	Φ87.8	53mm	0304891035
			500ml	4	Φ81	93mm	0304891036
			300ml	4	Φ63	93mm	0304891039
			100ml	8	Φ43	71mm	0304891038
				16	Φ38.5	73mm	0304891006
			50ml (conical)	16	Φ29.5	66mm	0304891033
				28	Φ29.5	75mm	0304891003
			50ml	16	Φ29.5	66mm	0304891037
				28	Φ29.5	73mm	0304891004
			20ml	40	Φ20	66mm	0304891163
			15ml (conical)	56	Φ17.5	82mm	0304891034
				64	Φ17	75mm	0304891005
			15ml	76	Φ17	71mm	0304891164
			7ml	96	Φ13.5	71mm	0304891165
			5ml	148	Φ13	71mm	0304891166
			1.5ml	224	Φ11.2	38mm	0304891025

Rotor	Cup	Adapter	Capacity (ml)	Place	Diameter mm	Depth (mm)	Order No
No.5 Swing Rotor Order No. 0302851600 Speed: 4000rpm RCF: 3040xg Capacity: 4x500ml	Test Cup 0303891022 Capacity: 4x500ml		300	4	Φ63	100	0304891142
			100	4	Φ38.5	107	0304891087
				8	Φ38.5	95	0304891009
			50	12	Φ29.5	72	0304891082
				16	Φ29.5	80	0304891007
			50 (conical)	16	Φ29.5	75	0304891008
			20	28	Φ21	72	0304851485
			15	36	Φ17	72	0304891083
			5	76	Φ14	72	0304851450
				80	Φ14	72	0304891010
	Carrier 0303851421 Capacity: 4x500ml		250	4	Φ63	95	0304891041
			50 Conical	16	Φ29.5	76	0304891075
				24	Φ29.5	76	0304891014
			50	16	Φ29.5	76	0304891107
				24	Φ29.5	74	0304891013
			15 Conical	40	Φ17	76	0304891074
				68	Φ17	76	0304891011
			15	40	Φ17	76	0304891104
			10	80	Φ16.5	76	0304891077
			5	112	Φ13.5	76	0304891081
			1.5	100	Φ11.2	76	0304891079
		Order No.0303851495 Capacity:4x2x96 places Elisa plate
		Order No.0303891011 Capacity:4x24x7/5ml Bucket
		Order No.0303891011 Capacity:4x37x7ml Bucket

Company Profile

CENCE is Chinese first centrifuge manufacturer. We’re engaged in centrifuge more than 40 years. We have certificates of ISO9001, ISO13485 and CE. We offer Origin Form A, Form C, Form D, Form E, Form F. Our products have been exported to more than 60 countries, such as USA, Germany, Japan, and Australia and so on. Our dream is to become international renowned centrifuge manufacturer.

Our company produces centrifuges' motors and rotors. The super capacity rotors of swing rotor 6 ×2400ml and has already passed rotor service life cycle test by authority of the United States in 2009 and surpassed the US standard of life cycle.

Hunan Xiang Yi Laboratory Instrument Co., Ltd.(hereinafter called Xiang Yi) is a hi-tech enterprise specialized in the manufacturing of centrifuges as well as lab instruments with a history over 50 years. China’s first Ultra Refrigerated Centrifuge(55000r/min) and first high-speed centrifuge (20000r/min) were made in Xiang Yi .

The company has passed the quality system certification by UK SGS and ISO9001: 2008, ISO13485:2012+AC:2012 : Certificate of Quality Management System for Medical device by German TUV respectively , assuring the stability and reliability of the product quality for 15 years effective operation.

The centrifuge technology developed by Xian Yi is at the leading level in China due to the technical cooperation with TOMY in Japan and BECKMAN in the USA during 80s and 90s of the last century.

The super capacity of 6x1000ml angle rotor and 6x2400ml swing rotor both have successfully passed the rotor service life test by the USA authority, which surpassed the US standard . This indicates that the performance of Xiang Yi Centrifuges have reached the international advanced level.

Along with the improvement of centrifuge technology and industry visibility, Xiang Yi is developing and expanding the product sales from domestic to overseas markets, such as USA, Germany, Japan, Uzbekistan, Kazakhstan, Kyrgyzstan ,Turkey, India, Mexico, Vietnam and more than 100 countries.

In order to meet the market demand, in 2006 Xiang Yi made giant investment to establish an RD and manufacturing center in Changsha, the capital city of Hunan, covering building area of 20,000 square meters, in which a special centrifuge test room, aging room, noise test room, explosion laboratory, debugging room and professional centrifuge assembly lines have been set up, promoting annual production capacity from 20 000 sets to 80 000 sets.

All the performance tests can be conducted within the company. Xiang Yi has jointly established an R&D center of laboratory instruments with famous universities. bringing together senior talents in this field. Xiang Yi has become well-known domestic production base of lab instruments.
